Shandong Shengyue Technology Development Co.,Ltd is one of the most professional weichai wd10 engien assembly wd10g220e21 manufacturers and suppliers in China. Please feel free to buy high quality genuine auto parts at competitive price from our factory.
WEICHAI WD10 ENGIEN ASSEMBLY WD10G220E21
Detailed Product Specifications
| Specification Item | Technical Data |
| Engine Model | Weichai WD10G220E21 |
| Type | In-line, 6-Cylinder, 4-Stroke, Water-cooled |
| Aspiration | Turbocharged & Intercooled (增压中冷) |
| Rated Power | 162 kW / 220 HP |
| Rated Speed | 2200 RPM |
| Max. Torque | 860 - 900 N.m |
| Displacement | 9.726 L |
| Bore × Stroke | 126 mm × 130 mm |
| Emission Standard | Euro II / Tier 2 |
| Fuel System | Mechanical Pump (Direct Injection) |
| Compression Ratio | 17:1 |
| Min. Fuel Consumption | ≤ 195 g/kW.h |
Physical & Logistics Data
| Item | Dimensions / Weight |
| Net Weight | 850 kg |
| Gross Weight | 1,020 kg (with Export Wooden Case) |
| Engine Dimensions | 1340 × 800 × 1150 mm |
| Packing Size | 1550 × 1000 × 1400 mm |
Application Scenarios
Primary Construction Machinery
LiuGong: CLG855, CLG856
SDLG: LG953, LG956
Lonking: CDM855, CDM856
XCMG: LW500 Series
Additionally, it is widely utilized in motor graders, bulldozers, truck-mounted cranes, and large-scale road rollers.
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
