Deutz TCD 2.9 L4 Engine
General Engine Specifications
| Item | Technical Data |
| Engine Model | Deutz TCD 2.9 L4 |
| Cylinder Configuration | Inline 4-Cylinder |
| Aspiration | Turbocharged, Charge Air Cooled |
| Displacement | $2.9$ Liters |
| Bore / Stroke | $92 / 110$ mm |
| Cooling System | Water-Cooled |
| Emission Standard | EU Stage IIIB / IV / V, US EPA Tier 4 Final |
Performance Data
| Parameter | Value |
| Max. Power | $55.4$ kW ($74$ hp) @ $2600$ RPM |
| Min. Power | $30$ kW ($40$ hp) @ $2200$ RPM |
| Max. Torque | $300$ N.m @ $1600$ RPM |
| Low Speed Torque | $215$ N.m @ $1000$ RPM |
| Specific Fuel Consumption | $215$ g/kWh |
Physical & Maintenance Dimensions
| Item | Specification |
| Engine Weight (Dry) | Approx. $230$ kg |
| Length | $626$ mm |
| Width | $490$ mm |
| Height | $741$ mm |
| Oil Change Interval | $500$ or $1000$ Working Hours |
| Injection System | High Pressure Common Rail (BOSCH) |
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
