Shandong Shengyue Technology Development Co.,Ltd is one of the most professional hangcha cpcd35-ag2 construction machinery forklift hydraulic transmission assembly yqx30a-g00 engine number 24162787 manufacturers and suppliers in China. Please feel free to buy high quality genuine auto parts at competitive price from our factory.
Hangcha CPCD35-AG2 Construction machinery forklift Hydraulic Transmission Assembly YQX30A-G00 Engine number 24162787
Basic Specifications
| Items | Technical Data |
| Product Name | Hydraulic Transmission Assembly |
| Compatible Model | Hangcha CPCD30/35-AG2 |
| Engine Match | Xinchai 498 / A498 / 4D27 Series |
| Transmission Model | YQX30A-G00 |
| Type | Power Shift (Hydraulic) |
| Speeds | 1 Forward / 1 Reverse |
Hydraulic System Performance
| Performance Indicator | Standard Value |
| Clutch Inlet Pressure | $1.1 \sim 1.4$ MPa |
| Torque Converter Inlet Pressure | $0.5 \sim 0.7$ MPa |
| Torque Converter Outlet Pressure | $0.2 \sim 0.3$ MPa |
| Lubrication Oil Pressure | $0.1 \sim 0.2$ MPa |
| System Flow Rate | $25 \sim 35$ L/min |
Transmission Ratio & Torque
| Item | Value |
| Torque Converter Ratio | $3.0 \sim 3.2$ |
| Forward Total Ratio | $1.25$ |
| Reverse Total Ratio | $1.15$ |
| Max. Input Torque | $350$ N.m |
| Rated Input Speed | $2500$ RPM |
Maintenance & Installation
| Maintenance Item | Requirements |
| Recommended Oil | No.8 Hydraulic Transmission Oil (or ATF Dexron III) |
| Initial Oil Capacity | $8.5 \sim 10$ Liters |
| Net Weight | $148$ kg (Including Torque Converter) |
| Filter Replacement | Every 500 Working Hours |
| Cooling Method | External Oil Cooler (Water-cooled) |
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
