Shandong Shengyue Technology Development Co.,Ltd is one of the most professional air cooled hydraulic oil cooler ah0608 manufacturers and suppliers in China. Please feel free to buy high quality genuine auto parts at competitive price from our factory.
Air Cooled Hydraulic Oil Cooler AH0608
FUNCTION
1. Efficient Heat Dissipation and Cooling
Utilizing a built-in aluminum alloy plate-fin heat exchange core and a forced-air fan, the unit rapidly dissipates heat generated within the hydraulic system into the surrounding air, thereby lowering the oil temperature.
2. Maintains Optimal Oil Temperature
It regulates the hydraulic oil temperature within an ideal operating range, effectively preventing overheating.
3. Protects Hydraulic System Components
It mitigates issues caused by high temperatures-such as reduced oil viscosity, oxidative degradation, and seal aging-thereby protecting core components (including hydraulic pumps, motors, valve blocks, and cylinders) and extending their service life.
4. Enhances Equipment Operational Performance
It ensures stable hydraulic system pressure and precise, smooth operation, making it particularly well-suited for prolonged, continuous heavy-duty applications.
Installation Location
Engine Compartment : Positioned near the hydraulic reservoir or main control valve block to facilitate easy connection of the return line.
Chassis Side or Bottom Mount: Secured to the chassis or the exterior of the engine compartment using angle iron or custom brackets, ensuring adequate ventilation.
Adjacent to the Return Line: Installed in series within the hydraulic system's return circuit.
Performance Advantages
| Category | Description | Benefits |
|---|---|---|
| Heat Dissipation | Plate-fin aluminum alloy structure + high-density fins + forced fan | Cooling capacity approx. 1.3-2.3 kW (1300-2300 kcal/h), rapid oil temperature reduction |
| Weight & Structure | Lightweight aluminum alloy, compact size | Light weight, flexible installation, ideal for limited space on mini excavators |
| Vibration Resistance & Durability | High vibration resistance, brazed process, working pressure ≤2.0 MPa | Withstands strong vibration and shock of construction machinery, longer service life |
| Energy Efficiency & Environmental | Low power fan (12V/24V, ~30-48W), no water cooling required | Energy saving, environmentally friendly, low operating cost, no leakage risk |
DETAILS
| DESCRIPTION | Air Cooled Hydraulic Oil Cooler | PART NUMBER | AH0608 |
| WEIGHT |
7 kg |
VOLUME |
35 × 22.5 × 14 cm |
| TRUCK MOLDE | SINOTRUK | QUALITY | Copy,High Copy, OEM,Original |
| MOQ | 1 | WARRANTY | 1 year |
| PAYMENT | TT/WESTEN UNION | SHIPMENT | by air/sea/railway |
| BRAND | SINOSACHS | PLACE OF ORIGIN | JINAN CITY,CHINA |
| STOCK | IN STOCK | APPLICABLE SITE | CABIN |
| PACKAGE | Carton/Woodenbox | PORT OF LANDING | Qingdao Port,China |
Maintenance & Replacement Recommendations
1. Regular Fin Cleaning: Every 1–2 weeks, use compressed air to blow away dust, dirt, and debris from the air outlet side toward the air inlet side. Perform a deep cleaning every 3–6 months to prevent fin clogging, which can lead to reduced heat dissipation efficiency.
2. Fan Operation Check: Before each operation, verify that the fan is rotating normally and without any unusual noises. Ensure that the fan's air intake and outlet remain unobstructed.
3. Leak Inspection: Visually inspect the oil line connections and the core body for any signs of oil seepage. Address any detected oil leaks immediately.
4. Mounting and Hose Inspection: Every 200 hours of operation, check the mounting brackets for looseness and inspect the hoses for signs of aging or wear.
5. Hydraulic Fluid Management: Regularly replace the hydraulic fluid and filter elements; maintaining fluid cleanliness can significantly extend the service life of the cooler.
6. Avoid: Direct washing with high-pressure water jets (which can easily damage the fins), and operating under heavy loads for extended periods without monitoring the oil temperature.
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
