Shandong Shengyue Technology Development Co.,Ltd is one of the most professional mitsubishi bosch cp3 series common rail high pressure fuel injection pump 0445020029 me223576 manufacturers and suppliers in China. Please feel free to buy high quality genuine auto parts at competitive price from our factory.
MITSUBISHI BOSCH CP3 Series Common Rail High Pressure Fuel Injection Pump 0445020029 ME223576
Applicable Vehicle Models and Engines
1. Primary compatible engine: Mitsubishi Fuso 4M50 series (4.9L displacement, 4-cylinder, direct-injection diesel engine, such as the 4M50-T).
2. Primary truck models: **Mitsubishi Fuso Canter** series (medium- and light-duty trucks).
3. Primary construction machinery (excavators): As the Mitsubishi 4M50 engine is frequently used in excavators from manufacturers such as Sany and Kato, this pump is widely installed on crawler excavator models including the Sany SY195, SY205, and SY215, as well as the Kato HD820-5.
Bill of Materials (BOM) for High-Pressure Fuel Pump (0445020029 / ME223576) Replacement
| No. | Part / Material Name | Specification / Core Parameters | Recommended Brand / Source | Qty | Unit | Replacement Remarks & Function |
|---|---|---|---|---|---|---|
| 1 | High-Pressure Fuel Pump | 0445020029 / ME223576 (BOSCH CP3 series) | BOSCH Genuine / Mitsubishi Fuso | 1 | pc | Core Component. Includes the high-pressure pump body, internal gear pump, and Fuel Metering Unit (IMV/MPROP). |
| 2 | Drive Gear O-Ring | Large diameter Viton/Fluororubber O-ring for pump nose | Included with pump / BOSCH gasket kit | 1 | pc | Mandatory Replacement. Fitted on the pump mounting flange/neck to prevent engine gear housing oil from leaking outward. |
| 3 | Inlet/Outlet Flange Washers | Copper or bonded rubber-metal washers (Typically M12/M14) | Included with pump / BOSCH gasket kit | 4~6 | pcs | Mandatory Replacement. Banjo bolt washers for the low-pressure fuel lines. Reusing old washers 100% causes diesel weeping or air suction. |
| 4 | Fuel Primary Filter | Diesel water separator filter element | Fleetguard / Parker Racor / Donaldson | 1 | pc | Mandatory Complement. Common rail systems are highly vulnerable to water. Water causes internal rust and plunger seizure. Must change when replacing the pump. |
| 5 | Fuel Secondary Filter | High-precision common rail diesel fine filter | Fleetguard / BOSCH Genuine / Donaldson | 1 | pc | Mandatory Complement. Filters out microscopic particles; the final shield for the pump and injectors. Must change when replacing the pump. |
| 6 | High-Pressure Line (Pump-to-Rail) | 1600+ Bar rated heavy-duty steel fuel line | Mitsubishi Fuso Genuine / OEM Spec | 1 | pc | Recommended Replacement. The sealing cone at the line end deforms slightly upon removal. Reusing it can lead to lethal high-pressure diesel spraying. |
| 7 | Metering Unit Wire Connector | 2-pin automotive waterproof plug kit (with pins & seals) | Matches BOSCH fuel injection loom | 1 | set | Replace as Needed. The IMV/solenoid plug runs hot and often becomes brittle, snaps, or suffers from poor contact due to diesel contamination. |
DETAILS
| DESCRIPTION | Common Rail High Pressure Fuel Injection Pump | PART NUMBER | 0445020029 ME223576 |
| WEIGHT | 8kg | VOLUME | 29 cm × 29 cm × 32 cm |
| TRUCK MOLDE | MITSUBISHI | QUALITY | Copy,High Copy, OEM,Original |
| MOQ | 1 | WARRANTY | 1 year |
| PAYMENT | TT/WESTEN UNION | SHIPMENT | by air/sea/railway |
| BRAND | SINOSACHS | PLACE OF ORIGIN | JINAN CITY,CHINA |
| STOCK | IN STOCK | APPLICABLE SITE | ENGINE |
| PACKAGE | Carton/Woodenbox | PORT OF LANDING | Qingdao Port,China |
Hot Tags: mitsubishi bosch cp3 series common rail high pressure fuel injection pump 0445020029 me223576, manufacturers, suppliers, factory, parts, genuine, original
