SINOTRUK SITRAK C7H HOWO T7H Oil-Bath Air Cleaner Assembly WG9725193410
Core Operating Principle and Technical Advantages
1. Oil-Adhesion Filtration: Dirty air drawn through the intake rushes downward at high speed, striking the surface of the oil in the sump before sharply reversing direction by 180 degrees to flow upward. Due to their high inertia, sand and mud particles in the air plunge directly into the oil, where they are firmly trapped and settle out.
2. Protection of the High-Value Main Filter Element: After undergoing this oil-bath filtration, the air passes through a metal mesh screen above, which captures approximately 80%–90% of coarse sand and dust. This significantly extends the service life of the engine's main paper air filter element and reduces the risk of catastrophic engine failures-such as cylinder scoring and premature valve wear-caused by sand ingestion.
Core Housing & Internal Filtration Modules
| Component Name | Recommended Qty | Critical Technical Specs / Assembly Reqs | Remarks |
|---|---|---|---|
| Oil Bath Air Cleaner Assembly | 1 Set | Genuine SINOTRUK WG9725193410 (Stainless steel/Corrosion-resistant steel) | Full metal housing including the upper shell, middle section, and lower oil sump pan. |
| Upper Stainless Steel Wire Mesh Filter | 1 Pc | Multi-layer wave-woven interlocking stainless steel mesh | Traps oil mist and fine dust particles; must be replaced if deformed, rusted, or clogged with unwashable sludge. |
| Lower Stainless Steel Wire Mesh Filter | 1 Pc | High-permeability heavy-duty stainless steel wire mesh | Guides air flow and provides primary blockage against coarse sand and stones. |
| Stainless Steel Oil Sump Pan (Dust Cup) | 1 Pc | Features factory engraved oil level marks (MAX / MIN) | Holds the engine oil required for wet filtration; replace individually if damaged by collisions or latch stripped. |
DETAILS
| DESCRIPTION | Oil-Bath Air Cleaner Assembly | PART NUMBER | WG9725193410 |
| WEIGHT | 20kg | VOLUME | 600 mm × 555 mm × 555 mm |
| TRUCK MOLDE | SINOTRUK | QUALITY | Copy,High Copy, OEM,Original |
| MOQ | 1 | WARRANTY | 1 year |
| PAYMENT | TT/WESTEN UNION | SHIPMENT | by air/sea/railway |
| BRAND | SINOSACHS | PLACE OF ORIGIN | JINAN CITY,CHINA |
| STOCK | IN STOCK | APPLICABLE SITE | ENGINE |
| PACKAGE | Carton/Woodenbox | PORT OF LANDING | Qingdao Port,China |
