HOHAN GOLDEN PRINCE WEICHAI WD615 engine fuel filter element 1000442956A
1.Core Function: Fuel Pre-filtration This filter element is responsible for filtering out large particulate impurities (such as water and sediment) from the fuel, protecting the high-pressure fuel pump and injectors, and serving as the first line of defense for the engine's fuel system.
2.Filtration Accuracy: Coarse Filtration (Pre-filter) This filter element is a coarse filter layer, primarily used to filter out large particulate impurities. It is typically located at the front of the engine and works in conjunction with a downstream fine filter to ensure the cleanliness of the fuel system.
3.Structural Features: Heated/Water Separator Some models (such as 614080739/740) have a heating function or a dedicated water separation structure to prevent fuel freezing in low-temperature environments or poor fuel injection due to excessive moisture.
DETAILS
| DESCRIPTION | engine fuel filter element | PART NUMBER | 1000442956A |
| WEIGHT | 1KG | VOLUME | 200*70*70 |
| MOQ | 1 | WARRANTY | 1 year |
| PAYMENT | TT | SHIPMENT | by air/sea/railway |
| BRAND | SINOSACHS | COUNTRY OF ORIGIN | CHINA |
| STOCK | IN STOCK |
APPLICABLE SITE |
ENGINE system |
Codes
Weichai fuel filter codes are typically quite complex, with two common types of codes
A. Original Part Number
This is the most accurate identification method, usually consisting of letters and numbers:
Common models: 612600081294A, 612600081334A, 612600081335A.
Code meaning: 0812 usually represents the fuel pre-filter for the WD615 engine.
B. General Code
General codes: CX0815, CX0814C.
Structure type: 614080739, 614080740 (with paper + non-woven fabric structure).
Performance Parameters
| PARAMETER | VALUE | DESCRIPTION |
| Flow rate range | 18-30 L/min | As a primary fuel filter for WD615 series engines (approximately 120-150 horsepower), the design flow rate is around 18-20 L/min to match the engine's fuel requirements. |
| Operating temperature | -30°C to 70°C | Paper + felt filter elements are usually designed for normal temperature environments; fuel may become thicker at low temperatures, but the paper structure has good cold resistance. |
| Filter element structure | Paper + Cotton | This system utilizes a paper filter element combined with a felt (or non-woven fabric) filtration layer. The paper layer is used to intercept large particles of impurities, while the felt layer further filters out fine particles and moisture, providing both filtration efficiency and good flow characteristics. |
Usage and Replacement Recommendations
1.Replacement Interval: It is recommended to replace the filter every 2000-3000 hours, or depending on the engine's operating environment (e.g., more frequent replacement is needed in dusty environments).
2.Inspection Points: When replacing, check the filter housing for corrosion and ensure the gasket is intact to prevent oil leaks.
3.Precautions: This is a coarse filter, used only for filtering large particles. If the engine experiences poor fuel injection (black smoke), check if the downstream fine filter is clogged.
