Shandong Shengyue Technology Development Co.,Ltd is one of the most professional 7 ways hose for heavy truck trailer parts manufacturers and suppliers in China. Please feel free to buy high quality genuine auto parts at competitive price from our factory.
The hose used for heavy truck trailer spare parts. With black clour and 7 ways.
For other trailer spare parts, brake shoe, bracket, brake drum and others,you can also inquire us.
FUNCTION
1. Transmits compressed air for trailer braking: The red coil (emergency/supply line) continuously supplies high-pressure air from the tractor's air reservoir to the trailer's air reservoir and spring brake chambers. When stopped, if air pressure is lost, the springs automatically extend and lock the wheels, ensuring the trailer does not roll. The blue coil (Service/Control Line) transmits the foot brake signal, inflating/deflating the trailer's regular brake chambers for on-demand braking.
2. Adapts to relative vehicle movement and prevents hose damage: The coil design is spring-like and expandable (compact in coiled state, can be stretched 2-3 times), allowing changes in angle and distance between the tractor and trailer during turns, inclines, declines, starts, and stops without breakage, twisting, or tangling. It prevents the hose from being scratched, crushed, or snagged on other objects while hanging on the ground, leading to leaks or breakage.
3. Ensures braking system safety and reliability: Features high burst strength, oil resistance, weather resistance, and low-temperature resistance. The emergency stop line (red) prioritizes parking braking; even if the service stop line (blue) breaks or leaks air, the trailer can still lock up due to spring force. This prevents air lock and pressure loss, ensuring timely response from both the foot brake and handbrake.
Advantages:
1. Extreme Dynamic Adaptability: The coils extend and retract freely like a spring (compactly coiled, with a stretch length of 2-3 times), perfectly adapting to changes in angle and distance between the tractor and trailer during turns, inclines, starts, and stops. They will not break, twist, bend, or excessively bend. They automatically extend when the turning radius is large and automatically retract when stopped, preventing them from drooping to the ground and avoiding being run over by tires, snagging on roadside objects, or becoming entangled in the drive shaft.
2. Highest Braking Safety and Reliability: The red emergency line (Supply/Emergency) continuously supplies air to the trailer's spring chambers. Even if the service line breaks or leaks, the trailer can still automatically lock the wheels using spring force to prevent rollover. The blue service line (Control/Service) precisely transmits foot brake control pressure, enabling instant braking.
DETAILS
| DESCRIPTION | 7 ways hose | PART NUMBER | - |
| WEIGHT |
1.5KG |
VOLUME |
15 cm × 10 cm × 4 cm |
| TRUCK MOLDE | SINOTRUK | QUALITY | Copy,High Copy, OEM,Original |
| MOQ | 1 | WARRANTY | 1 year |
| PAYMENT | TT/WESTEN UNION | SHIPMENT | by air/sea/railway |
| BRAND | SINOSACHS | PLACE OF ORIGIN | JINAN CITY,CHINA |
| STOCK | IN STOCK | APPLICABLE SITE | CABIN |
| PACKAGE | Carton/Woodenbox | PORT OF LANDING | Qingdao Port,China |
Maintenance Schedule (Recommended Reference) for Coiled Air Brake Hoses (盘管式空气制动软管)
| Maintenance Item | Recommended Interval | Operation Content & Standards |
|---|---|---|
| Daily Visual Inspection | Before each departure / Daily | Check the coiled hoses for cracks, wear, aging/cracking, deformation, or signs of leakage; confirm red and blue colors are clear and not mixed up; stretch and retract the coils several times to ensure smooth movement without sticking |
| Leakage Test | Every 5,000–10,000 km | Build system pressure to 8–10 bar, apply hand brake or foot brake, spray soapy water over the entire length of the coils, fittings, and gladhand connections; observe for bubbles; listen for any continuous "hissing" sound |
| Stretch Performance & Mounting Check | Every 10,000–20,000 km | Fully extend the coils to maximum length and check for even retraction without localized hardening; confirm hangers/clips are secure, coils do not drag on the ground, rub against tires, or contact hot components (e.g., exhaust) |
| Thorough Cleaning & Visual Inspection | Every 3–6 months or after rain/snow | Clean the coil surface with clean water or neutral detergent to remove oil, mud, salt, and debris; inspect for UV aging (whitening/brittleness), chemical corrosion, or surface damage |
| Preventive Replacement (Full Set) | 3–5 years or 500,000–800,000 km | Replace both red (emergency) and blue (service) coils together regardless of visible damage, especially when reaching service life or showing: cracking, hardening, leakage, poor retraction, corroded fittings |
| Emergency Inspection (When Abnormal) | Immediately | If abnormal braking noise, delayed braking, trailer rolling/sliding, low-pressure warning, or visible damage/leakage on coils → stop immediately, inspect, and replace as needed |
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
