Shandong Shengyue Technology Development Co.,Ltd is one of the most professional sinotruk howo truck air cleaner assembly zz5168g4210d1 manufacturers and suppliers in China. Please feel free to buy high quality genuine auto parts at competitive price from our factory.
SINOTRUK HOWO TRUCK Air Cleaner Assembly ZZ5168G4210D1
FUNCTION
1. Cyclonic Centrifugal Pre-filtration: As air enters the assembly housing tangentially from the side, it generates a high-velocity swirling airflow. Under the influence of centrifugal force, over 80% of coarse dust and particulate matter in the air is flung outward toward the housing walls; it then slides down the side walls into the bottom-mounted "duckbill" dust discharge valve, where it is automatically expelled. This process significantly extends the service life of the internal paper main filter element.
2. Micron-level Precision Filtration: The internal filter element is constructed from polypropylene fibers or nano-composite filter paper, enabling it to effectively capture minute dust particles ranging from 2 to 5 microns. With a filtration efficiency exceeding 99.5%, it prevents premature wear and cylinder scoring within the engine.
3. Reduced Intake Noise: The internal chamber design of the air filter housing also functions as a muffler, effectively dampening the intense, pulsating roar generated by the airflow during the diesel engine's intake stroke.
DETAILS
| DESCRIPTION | Air Cleaner Assembly | PART NUMBER | ZZ5168G4210D1 |
| WEIGHT | 5.5 kg | VOLUME | L=520 mm |
| TRUCK MOLDE | SINOTRUK | QUALITY | Copy,High Copy, OEM,Original |
| MOQ | 1 | WARRANTY | 1 year |
| PAYMENT | TT/WESTEN UNION | SHIPMENT | by air/sea/railway |
| BRAND | SINOSACHS | PLACE OF ORIGIN | JINAN CITY,CHINA |
| STOCK | IN STOCK | APPLICABLE SITE | ENGINE |
| PACKAGE | Carton/Woodenbox | PORT OF LANDING | Qingdao Port,China |
Routine Inspections and Assessment Criteria
1. Observation of the Intake Restriction Indicator: A vacuum indicator is installed on the piping located downstream of the air filter assembly. As long as the red line remains outside the "danger zone," it indicates that the filter element is allowing for proper airflow; therefore, do not frequently remove it for cleaning. Frequent removal and reinstallation can damage the sealing ring, thereby increasing the risk of unfiltered air bypassing the filter. If the indicator displays red, the filter element must be cleaned or replaced at the end of the workday.
2. Daily Inspection of the Duckbill Dust Ejector Valve: Before commencing operations each day, manually squeeze the rubber duckbill dust ejector valve located at the bottom of the air filter housing. If a significant amount of sand, dirt, or leaves has accumulated inside, squeeze the valve open to expel the debris immediately. If the duckbill valve is found to be cracked, deformed, or missing, it must be replaced immediately; otherwise, unfiltered air will bypass the intake inlet and leak directly into the system through this opening, resulting in the instantaneous failure of the main filter element.
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
